Fixing Concrete Patio Cracks: DIY Guide for Joliet Homeowners

Noticed some unsightly cracks in your concrete patio? Don’t worry; it’s a common issue that many of us face. The good news is that fixing these cracks is not as daunting as it seems. In this guide, we’ll walk you through the steps to repair those cracks and share some tips on how to prevent them in the future. Let’s make your patio look as good as new!

Understanding Concrete Patio Cracks

As homeowners in Joliet, we take pride in our outdoor spaces, and a concrete patio is often the centerpiece. However, even the sturdiest patios are prone to cracking. Understanding the nature of these cracks is key to maintaining your patio’s beauty and functionality. Let’s dive into the reasons behind these cracks and how they affect your beloved patio.

Why Do Cracks Happen?

The concrete patio in your property is not just a surface; it’s a canvas of your home’s story. But, like any story, it sometimes faces challenges. In Joliet, various factors can cause your patio to crack, and understanding these can help you in maintaining its integrity.

Soil Movement: One of the primary causes of patio cracks is the movement of the soil underneath. Over time, especially in areas like ours that experience heavy rain or prolonged drought, the soil can settle or shift. This movement places uneven pressure on the concrete above, often leading to the formation of cracks. It’s a natural process, but one that can significantly affect the integrity of your patio.

Freeze-Thaw Cycles: Another factor particularly relevant to us in Illinois is the freeze-thaw cycle that comes with our tough winters. When water finds its way into tiny crevices in your patio, it freezes as temperatures drop. Frozen water expands, widening these small cracks. Then, as the ice thaws with rising temperatures, it leaves behind larger gaps. This cycle can repeat throughout the winter, gradually worsening any existing fissures in the concrete.

Tree Roots: Additionally, the beautiful trees that adorn our yards can inadvertently cause damage to patios. As tree roots grow and extend underground, they can exert pressure against the underside of the concrete. This pressure can lead to cracks or even cause sections of the patio to lift and become uneven. While trees add beauty and value to our properties, their root systems need to be considered when assessing the health of our patios.

Types of Cracks

Understanding the type of crack you’re dealing with on your patio is a key step towards effective repair. Each kind of crack, from the barely visible hairlines to the more concerning structural ones, tells a different story about the state of your patio. Here’s a quick guide to help you identify the type of crack and understand what it means for your repair strategy:

Hairline Cracks: Hairline cracks are the fine lines that barely catch your eye but are indeed present. Typically thin and shallow, they often emerge due to the natural settling of the concrete or minor shrinkage as it cures. While they might not be pleasing to look at, hairline cracks usually don’t pose a structural threat to your patio. They can be easily filled and sealed to prevent water infiltration and further widening.

Deep Cracks: In contrast to hairline cracks, deep cracks are wider, more noticeable, and penetrate deeper into the concrete. These types of cracks often signal more serious issues, such as significant soil movement or freeze-thaw cycles having a substantial impact. Deep cracks require more extensive repair methods as they can potentially affect the stability of the entire patio area. They may also be a sign of substandard concrete installation or an indication that the ground beneath the patio was not properly prepared.

Structural vs. Non-Structural Cracks: Distinguishing between structural and non-structural cracks is crucial for appropriate repairs. Structural cracks, often wider than a quarter-inch, are more than just an eyesore – they can compromise the integrity of your patio. These cracks might indicate a foundational issue and often require professional assessment and repair. On the other hand, non-structural cracks, while unsightly, are typically not a sign of major problems. They don’t generally impact the patio’s durability but addressing them promptly can prevent them from developing into more significant issues.


Identifying the type of crack helps you choose the right repair method and materials, ensuring a lasting fix.

Preparing for Repair

Before diving into the repair process, a bit of preparation goes a long way. Here’s how you can set yourself up for a successful repair job:

Assessing the Damage

  1. Visual Inspection: Start with a detailed examination of your patio. Walk around and take note of every crack, however small. Pay attention to their lengths and widths – are they long, branching out across the patio, or are they short and isolated? This visual mapping will help you understand the extent of the damage and plan your repair strategy accordingly.
  2. Depth Check: Surface cracks can often be deceiving. To gauge how deep they go, use a small tool like a screwdriver or an ice pick. Gently insert it into the cracks to feel their depth. This step is important because the depth of the cracks determines the type of filler or repair material you’ll need. Shallow, surface-level cracks can usually be fixed with simple sealants, while deeper cracks might require a more robust repair approach.
  3. Structural Assessment: Not all cracks are created equal. If you come across cracks that are wide, uneven, or if the patio slab seems to be tilting or unstable, these could be signs of structural issues. Such cases often go beyond cosmetic fixes and might indicate problems with the foundation or the soil underneath. If you suspect structural damage, it’s prudent to call in a professional. A structural engineer or a professional concrete contractor can provide an expert assessment and recommend the best course of action.

Tools and Materials Needed

Equipping yourself with the right tools and materials is essential for a successful patio repair. Whether you’re dealing with narrow or wide cracks, having the appropriate items at your disposal will ensure a smooth and effective repair process. Here’s a breakdown of what you’ll need for different types of cracks on your concrete patio:

For Narrow Cracks

  • Masonry chisel and hammer for opening the crack.
  • Wire brush for thorough cleaning.
  • Concrete crack filler for sealing the crack.
  • Caulking gun to apply the filler.
  • Putty knife or trowel for a smooth finish.

For Wide Cracks (includes everything for narrow cracks, plus)

  • Vinyl concrete patching compound for a stronger repair.
  • Trowel for mixing and applying the compound.
  • Sledgehammer and larger chisel for undercutting and proper preparation

Repairing Narrow Cracks

Narrow cracks, while not a major structural concern, can become worse over time if not addressed. Here’s how to effectively repair them:

  1. Cleaning the Crack
    • Remove Debris: Use your wire brush vigorously to clean out the crack. This includes dirt, pebbles, and loose concrete fragments.
    • Wash and Dry: For a thorough clean, wash the crack with water and let it dry completely. This ensures the filler adheres properly to the concrete.
  2. Applying the Filler
    • Choosing the Right Filler: Masonry concrete crack fillers are ideal for narrow cracks. They come in tubes, much like caulk, and are designed to work with a caulking gun for easy application.
    • Filling the Crack: Insert the filler tube into the caulking gun. Apply the filler along the length of the crack, ensuring it penetrates deeply. Overfilling is okay – you’ll be smoothing it out later.
    • Smoothing the Surface: Use a putty knife or trowel to smooth the filler, making it level with the rest of your patio. This step is crucial for both aesthetic reasons and to prevent water from pooling in the repaired crack.
  3. Curing Time
    • Let It Dry: Refer to the filler’s instructions for drying times. Usually, 24 hours is sufficient, but some products may differ. Avoid walking on or wetting the repaired area during this time.

Repairing Wide Cracks

Wide cracks in your patio can be daunting, but with the right approach, you can fix them just as effectively as the narrow ones. Here’s how:

  1. Undercutting and Cleaning
    • Undercutting the Edges: This is a crucial step for wide cracks. Use your sledgehammer and chisel to gently chip away at the edges beneath the crack, creating an inverted V-shape. This helps the new patching material to lock in place and not pop out.
    • Thorough Cleaning: After undercutting, use your wire brush to clean inside the crack. Remove all debris, dirt, and loose concrete to ensure a strong bond between the old surface and the new patch.
  2. Filling and Sealing
    • Selecting the Right Filler: A vinyl concrete patching compound is ideal for wide cracks. It’s strong and can adhere well to existing concrete.
    • Mixing the Compound: Follow the manufacturer’s instructions to mix the compound. It should have a consistent, paste-like texture.
    • Applying the Compound: Use a trowel to apply the compound into the crack. Push down firmly to remove air pockets and ensure deep penetration into the crack.
    • Leveling the Surface: Smooth out the compound with your trowel, making it flush with the rest of the patio. Aim for a smooth, even surface.

Finishing Touches

Once you’ve repaired the cracks, a few finishing touches can make all the difference in restoring your patio’s appearance and ensuring the longevity of your repairs.

Smoothing and Blending

  • Sanding: If you’ve used a patching compound for wide cracks, let it dry fully. Then, gently sand the repaired area with fine-grit sandpaper to ensure it’s smooth and level with the rest of the patio.
  • Cleaning the Area: After sanding, sweep or rinse off the patio to remove any residual dust or debris. This step will not only clean your work area but also help you inspect the repair job.

Sealing the Repaired Area

  • Applying Sealant: Once your repairs are dry and smooth, consider applying a concrete sealant over the repaired area. This will protect the repair from weather elements and make it last longer.
  • Choosing a Sealant: Look for a sealant suitable for outdoor use and compatible with concrete. Apply it according to the manufacturer’s instructions for the best results.

Curing Time and Care

  • Allow Adequate Drying: Give the sealant enough time to dry and cure. Check the product label for specific drying times.
  • Post-Repair Care: Avoid heavy traffic on the repaired area for a few days to allow the repairs to set completely.

Preventing Future Cracks

Repairing cracks is great, but preventing them in the first place is even better. Here are some tips to keep your patio in top shape and minimize future cracking:

Proper Patio Installation and Maintenance

  • Quality Installation: When it comes to installing a new patio or redoing an existing one, ensure the concrete mix is correct. An improper mix, especially with too much water, can lead to weaker concrete prone to cracking.
  • Control Joints: Incorporating control joints in your patio design can help manage where cracks occur, usually in straight lines along the joints, making them less noticeable and easier to maintain.
  • Regular Inspections: Periodically inspect your patio for early signs of wear or small cracks. Early detection makes repairs easier and less costly.
  • Regular Cleaning: Maintaining the cleanliness of your patio is just as important as the structural aspects. Regular cleaning helps to prevent build-up of dirt and debris, which can contribute to surface damage over time. A clean patio not only looks more inviting but also allows for easier inspection and maintenance.

Weatherproofing and Care

  • Sealants: Applying a concrete sealant can create a barrier against moisture, chemicals, and temperature changes. This is especially important in Joliet, where freeze-thaw cycles are common.
  • Reapplication of Sealant: Concrete sealants wear off over time. Reapply them every few years, following the product’s guidelines.
  • Proper Drainage: Ensure your patio has proper drainage to prevent water accumulation, which can weaken the concrete and lead to cracks.
  • Avoid Deicing Chemicals: In winter, avoid using deicing chemicals on your patio. These can cause surface damage and increase the likelihood of cracking.


That’s a wrap on your concrete patio repair journey in Joliet! With every crack fixed and sealant applied, you’ve not only enhanced the durability of your patio but also its charm. Remember, your handiwork doesn’t just make your outdoor space look great—it’s the foundation for memories under the Illinois sky. Here’s to enjoying many beautiful days on your very own patch of paradise!
